XLPE/PVC Insulated Cable Wire Steel Wire Armored Cable for Underground Transmission Lines
XLPE insulated power cable has the advantages of not only high mechanical strength, good ambient stress resistance, good electrical properties and anti-chemical corrosion, but also simple construction, light weight and convenient to use. It applies to electrical power trensmission and distribution lines with A.C. rated voltage U0/U up to and including 0.6/1kV.
Characteristics & Applications
Characteristics & Applications
The main feature of the flame retardant XLPE power cable is hard to get fire or that the continous burning of cables is vert limited when it is on fire. It applies to the places with many cable is laid tightly together such as power-generated station, subway, tunnel, hight-storey building, large-sized factory and mines, oil field and coal mine.
StandardsThe products can be produced in accordance with GB, IEC, BS, and other standards.
Basic InformationModel No: YJV YJLV VV VLV VY VLY VV22 VV23 VV33 etc.
Material Shape: Round Wire
Range of Application: Power Grid and All Industry
Certificate: ISO9001,ISO14001, CCC, CE
Brand Name: GDYG
Specification: 0.5mm2 - 630mm2
Supply Record: America, Australia, African countries, Arabian countries, Asian countries etc.
Origin: Guangdong, China
Application: Power Grid, Transmission Line, Construction, Railway Transportation, Chemical Plant, Telecom , Oil Industry, Equipment Manufacture, Instrument Industry etc..
Voltage: 35KV, 10KV, 0.6/1KV, 450/750V, 300/500V
Current: AC & DC
Insulation Material: XLPE, PVC etc.
Sheath Material: XLPE, PVC etc.
Material Shape: Round wire
1. the rated voltage U0/U is from 0.6/1kV to 26/35kV.
2. Maximum conductor temperature under normal operation is 90ºC.
3. Maximum conductor temperature under short circuit (Max duration is not more than 5s) is not more than 250ºC.
4. Minimum installation ambient temperature is not less than 0ºC.
Installation bending radius are not less than the following specified values:
Single core non-armored cable: 20D
Single core armored cable: 15D
3 cores non-armored cable: 15D
3 cores armored cable: 12D
(Note: D-outer diameter of cable)
Voltagela class 26/35kV
Type: YJV YJLV ZC-YJV ZC-YJLV
|reference weight |
of finished cable
Voltagela class 12/20kV
Type: YJV22 YJLV22 ZC-YJV22 ZC-YJLV22
|reference weight of finished cable |
Established in 1988, as one of the main enterprise of Vango Group, Guangdong Vango Cable Industry Co., Ltd. It covers 214000m² with about 110 sets international advanced cable and wire producing and testing equipment. There are 540 employees including over 116 intermediate and senior technical personnel with 9 senior titles which contributes strong power of scientific research, management and innovation. It gains 21 Patents issued by State Intellectual Property Office of China.
The main products are power cables with rated voltage up to 35kV, common type, fire-resistance and flame retardant PVC cable with voltage up to 1kV, control cable of 450/750V, PVC insulated cable and wire, AAC, ACSR, ACSR/AS, heat-resistant Aluminum Alloy Conductor and aerial insulated cable up to 35kV, which covers 8 series with more than 3000 items. The researching and manufacturing of conductor applied in 500kV to 1000kV ultra-high voltage DC transmission line is in the domestic advanced level. Guang Brand products have been widely supplying to the key engineering projects of State Grid Corporation of China and China Southern Power Grid, such as ±800kV DC Transmission Line from Yunnan to Guangdong, ±500kV DC Transmission Line from Xi Nuodu Power Station to Guangdong, ±800kV DC Transmission Line from Nuo Zhadu Power Station to Guangdong and etc. The products are exporting to Pilipinas, Cambodia, South Africa, Madagascar and other countries.
Why Choose us?
♥ Strict Quality Control System Reliable Qualty Taking The Lead:
In 2001, as the first in the industy, Guangdong Vangou Cable Industy Co., Ltd. passed the certifications of the ISO9001 quality system and metrological system. Its prodution is strictly submitted to such international and national standards as IEC, GB and BS. Its all products have the national production locense; passed the national CCC certification. Its first grade quality wins customer's favor.
♥ First Grade Production Equipment and Environment, High Standaed Makes True Value:
The company is well-equippede. The main manufacturing facilities are Wire-drawing group for Aliminum Alloy and Line Mold which is the second set of China 2010, SIKORA measuring Device, CLY-3/2000 Cabling Machine, LHD-450/13 Sliding Aluminum Drawing Machine, JLK-6+12+18+24/630 Frame-type Strander and CCV-0+3/65+150+90 Triple Extruction Cross-link Production Line etc. which forms the production capacity of super standard cable with rated voltage from 0.6kV to 1000kV.
1. Are you a trading company or manufacture?
We are a wire and cable Manufacturer with 30 years history almostly, our factory located in Qingyuan, Guangdong Province, China.
2. What is your main product?
As one of leading cable manufacturers in China, we are specialized in power cables with rated voltage up to 35kV, common type, fire-resistance and flame retardant PVC cable with voltage up to 1kV, control cable of 450/750V, PVC insulated cable and wire, AAC, ACSR, ACSR/AS, heat-resistant Aluminum Alloy Conductor and aerial insulated cable up to 35kV, which covers 8 series with more than 3000 items.
3. Can you offer me a free sample?
Yes, sample is free but the freight charge should be borne by you.
4.How is the payment?
T/T, L/C is acceptable.
5. What is the lead time for mass production?
It depends on the order quantity and the season you place the order. Normally within 1 month.
6.Do you accept OEM or ODM?
Yes, we accept OEM and ODM. Your logo and company name can be printed on our products.
7.Do you have after-sale service?
Yes, 12 months warranty.
